WARNING
10 Safety Version: G/14/6/21/1
WARNING!
Maintenance and repair work on the plant may only be carried out by
persons who have been trained for this activity on ENGEL robots!
They must have comprehensive knowledge of safety precautions and
operating elements!
The activities and maintenance intervals described in the Instruction Manual must be
observed.
Additionally, maintenance periods must be observed and maintenance activities must be
carried out on all safety devices for the protection of personnel and equipment according to the
safety regulations in force in your country by your authorities.
Further work on the machine going beyond the described activities may only be carried out by
the ENGEL customer service.
1 ACCIDENT PREVENTION
u During work on the plant wear the prescribed, personsal protection clothes (safety
boots, safety gloves, safety goggles, etc). Observe the local safety regulations for the
reliability in operation of injection molding lines!
u Always keep the equipment clean. This contributes considerably to serviceability and so
biggest possible safety for the operating personnel.
u Do not remove any warning or information signs and markings from the machine or
additional devices!
u Observe possible obstacles in the operator work area when stepping through the robot
teach sequence. Ensure the robot does not collide with the downstream equipment or
the Injection Molding Machine!
u When working around hot components, such as the material barrel and molding area,
wear safety gloves and safety goggles!
u Switch off motors, during all work carried out in the movement areas of the machine!.
n The leaning of ladders is not allowed!
u Do not turn the control voltage or main voltage OFF during axis movement. This applies
when operating in all modes of operation.
u Before turning the pneumatic system OFF, move the robot into the deposit area and
remove any parts from the end of arm tooling. In case pressure is lost, ensure the end
of arm tooling is rotated down to prevent an uncontrolled downward swivel.
u The maximum manipulation weight of the robot must not be exceeded.
国 During operation no cleaning and maintenance work may be carried out!
u During maintenance and service work on the vertical axis this must be protected
mechanically (see chapter Maintenance).
n Pay attention to that the control cabinets are always closed. No dust and no humidity
may penetrate.
u Protect all hoses against damage from, for example acids or mechanical abrasion.
u Check all pipings for their work-safe state regularly. Switch off the plant immediately
when you detect a leakage, damage or break of a piping.
u No access for unauthorized persons on the plant and/or on the robot!
