This M-32-F spring-balanced loader (right) )
is ideal for bottom loading petroleum-based
products, including gasoline, diesel,
biodiesel and ethanol.
{ This G-32-F (left) is attached to a riser located at ground level. It offers
an easy way to bottom unload a railcar. While not in use, you can see
how it is easily “parked” outside the railroad envelope. Further down
the tracks, you can see a hose attached to a riser, inside the envelope
and perilously close to the rail.
T
The photo to the right shows a bypass loading arm. In this 人
application, the loading arm is not carrying product but is
carrying the load of the pipes above it. This application is
typical of a situation where the customer wanted to use
components that were compatible with the liquid, plus
needed the arm to act as a support, holding the load while
making it easy to manipulate and control loading.
< |
ae { The photo to the left shows how loading arms can be made to
crossover each other to facilitate loading of various compartments
in a tanker truck. Note the canopy. Its height limited the vertical
travel of the loading arms. Design considerations like this are very
important. Your OPW sales representative will be glad to make an
on-site evaluation of your loading area.
