From more than half century of manufacturing experiences with one of the top supplied record in the world, TB-NIIGATA gives you the reliability of truck loading arm in an economical package. FEATURES TB-NIIGATA tank/rail loading arms features safe and time saving loading operation with long life time. It can be applied for almost all liquid/vapor application. High Pressure Chemical L O SELECTION GUIDELINES Arm Type M Top Loading TSLA with torsion spring balance unit is generally adapted to open dome loading of petroleum products and chemicals. VRA with air actuator balance unit is generally adapted to closed dome loading with vapor recovery system for the application of volatile fluids. Steam jacketed type VRA is available for high temperature service. m Bottom Loading SBLA is particularly suited for closed system loading products such as LPG, chemicals, and fuel products with API coupler. CBLA is generally adapted to cryogenic application such as LNG. M Standard Size M Length of Arm Flow rate, loading time, pressure drop and other factors to decide Arm length to be considered by writing working range size/diameter of loading arm. from installation point of arm to truck/tanker flange or hatch. For smooth operation, most appropriate length is considered for each requirement. Products Size (Diameter) | Max. Flow Rate Launypastal| ainches 80ms etoleum /Badk | 4inches 120ms Lauid| 2inenes 80ms Liquefied 3 inches 120ms Gas Gas 1 inches 50mas * For the detail on the size for specific products, please contact us. 03
