Model AC/TC-50Belt Box Pumps 1x2x6-2515x25x10and2x4x8.5Features & Benefits= Rugged high speed belt box:Excellent for intermittent duty,high power/flow applicationsDesign does not require an inverterduty motor to obtain high speed,high pressure applicationsExcellent cold creep barrier toprotect motor bearings= Impeller design allows for low NPSHrequirementAll bronze construction allows forO, compatibilitySpecificationsPump SizeFlow RangeNPSHRDifferential HeadSpeed RangeApplications= Liquid storage transfer= Small and medium plant transfer andpipeline back-up= Tank car unloadingLiquids PumpedNitrogenOxygenArgon= MethanePump Design Ratingunits 1.5x25x 10gpm 20-200Ipm "\ 75- 750fe;—本 9 2-12meter = 06-4~ feet 200-1500Cs 60 -455hp 25- 100kw 19-75o rpm 3,650 - 8,750Consult Nikkiso ACD engineering to confirm available sizes and ratings.Typical Scope of Supply= Pump, TEFC motor, and highperformance belt box drive shown* Mechanical seal purge portsOptional AccessoriesPump skid assemblyBearing purge kitSpare parts kit= Mechanical seal (CFS) ensures long life= Bearing/belt box purge ports providedfor O, applications
