Model AC/TC-21Belt Box Pumps 75x1x4,1x2x4.5,1x2x6,1x2x6-25and 1.5x2.5x6CSpecificationsPump Size units 1.6x2.6x6Cgpm 10-180Flow Range =Ipm 35- 680feet 2 一 8NPSHR 二—meter 0.6-25feet 100-1,100Differential Head Nmeter 30-335hp 5-40Pump Design Ratingkw 3.75 - 30Speed Range rpm 2,000 - 10,500Consult Nikkiso ACD engineering to confirm available sizes and ratings.Features & BenefitsBelt drive design allows for higherspeedsBelt tension mechanism increases lifeof the timing belt and bearingsLightweight aluminum belt housingconstruction reduces overall pumpweightBelt drive components have “full toothengagement” for greater capacity andlonger lifeBearing purge ports are provided forliquid oxygen applicationsCold end can be removed as a singlepiece, simplifying maintenanceAll bronze construction allows forO, compatibilityApplicationsLiquid storage transferLiquid cylinder fillingTrailer off-loading (ground mount) Test facility supportLaboratory researchLiquids PumpedNitrogenOxygenArgonMethaneTypical Scope of SupplyPump, belt box, TEFC motor shownGrease packed bearingsMotor purge portsLong life mechanical seal (CFS)
