Model AC/TC-30Close Coupled Pumps Multiple sizes availableSpecificationsPump Size units Multiplegpm 15 - 2,000Flow Range —Ipm 60- 7570feet 2 —12NPSHR A 2meter 06-4feet 20-3,000Differential Head )meter 6-915hp 3-400Pump Design Ratingkw 2.2-300Speed Range rpm 1,450 - 7,200Consult Nikkiso ACD engineering to confirm available sizes and ratings.Features & Benefits= Close coupled design provides:- Operations at high efficiencies- Fewer moving parts- Lower maintenance costs= Shaft seal design (mechanical, gasriding or labyrinth) are state-of-the-artand prolong life without leakage= VFD compeatibility allows for multipleoperating speeds= Minimum recirculation wear ringsreduce maintenance requirements andimprove efficienciesApplications= Liquid storage transfer= Process plantTruck and trailer off-loading Tank car unloadingLiquids PumpedNitrogen= Oxygen= Argon= Methane= Nitrous Oxide= Carbon DioxideTypical Scope of Supply= Pump and TEFC electrical motor shown* Long life CFS mechanical seal= Motor and seal purge ports
