14/ ACD - Cryogenic Pumps EditionModel TC-34Submerged Motor PumpsSpecifications Pump Size units 1x2x6-28gpm 2-120Flow RangeIpm 8-450feet 1.5-12NPSHR . N Smeter 05-4feet 50 - 1,200Differential Head 1}meter 15 -365hp 10 upto 44Pump Design Ratingkw 7.5 up to 33Speed Range rpm 1,500 - 7,200 Consult Nikkiso ACD engineering to confirm available sizes and ratings. 1x2x6-2S8/4Sand1.5x2.5x6 -2SNot suitable for Oxygen serviceFeatures & Benefits Applications Optional Accessories= Gastight design Use where product loss is not acceptable = Vacuum jacketed sump= Pump and motor are fully submerged = Liquid storage transfer = Variable frequency drivein liquid minimizing loss and = Mobile delivery transfer — LAR, LN, = Differential pressure gaugeguaranteeing quick response pumping . ) . ) o= Vehicle fueling stations — LNG = L oss of prime detector (cavitation= Vacuum jacketed sump provides protection)extremely low heat leak — idealpumping conditions (optional) eeLiquids Pumped = Dual conduit box per NFPA standardsfor LNG serviceSealless and submerged designminimizes maintenance requirements = Nitrogen= Vertical pump design provides greater = Argonstability and longer life - Ethylene= Special design VFD motor provides S Ethanebroad range of operation= Methane= Propane= Hydrogen
