ACD - Cryogenic Pumps EditionVertical Turbine PumpsState-of-the-Art Submerged Motor PumpsVTK-240Multiple sizes available Features & BenefitsHighly efficient, over 70% — loweroperating costs and heat input intothe fluidModular design, 60 PSl/stageActive thrust balancing system forextended bearing lifeHigh efficiency hydraulics withextremely low NPSHR inducerLightweight and compactAvailable in sump and in-tank designsSpecial design VFD drive providesoperation point control over the entirepump operating rangeFeatures a quick electrical disconnectfor ease of maintenancePermanent magnet motorAll parts from wrought aluminum areprecision machinedVacuum jacketed sumpHeavy duty ceramic bearingsSpecifications gpm 1,000 - 2,500Flow RangeIpm 3,785 - 9,462feet 2=5 (62 -2,800 gpmNPSHR N & L SPmieter 0.6 -1.5 (613 - 10,598 Ipm)feet 46 - 1,937Differential Head VU ©meter 14 - 590hp 167.5-335Pump Design Rating -kw 125 - 250Speed Range rpm 2,000 - 4,200Consult Nikkiso ACD engineering to confirm available sizes and ratings.ApplicationsBunkering — barge-to-shipLow pressure marine fuel systemsSend-out pumpLiquid storage transferBunkering operations — ship-to-shipPipeline feedFSRU loading/off-loadingRailcar tender car loading andunloadingLiquids Pumped= Nitrogen= Argon= Ethylene= Ethane= Methane= PropaneComplete Pumping System= High-efficiency submerged pump= Removable in-tank with foot valve= Custom made VFD drive — factorystring tested= Dual electrical feed thru hermeticallysealed up to 500AOptional AccessoriesDifferential pressure gaugeLoss of prime detector (cavitationprotection)Safety relief valveDual conduit box per NFPA standardsfor LNG servicesComplete removal systemsLong term storage container
