ACD - Cryogenic Pumps Edition \23Model SGCL 41.3Cylinder Filling PumpsSpecificationsgpm 1.05 -4.75 Flow RangeIpm 4-18bar 01-0.68NPSP iy B Ometer 0-10bar 420Maximum Discharge Pressure Tmeter 6091s B R hp 16-40ump Design Ratin -_—P = g kw 11-30Speed Range rpm 100 - 450 Consult Nikkiso ACD engineering to confirm available sizes and ratings. Features & Benefits Applications= Single, double or triple cylinders modular = Splash oil lubricated drive allows = Specially designed for heavy duty, highdesign provides a wide range of flow higher bearing loads and increases the pressure cylinder and storage fillingrates reliability = Light to medium cylinder filling for flow= Vacuum jacketed cold ends for minimal = Easy maintenance concept with rates up to 5 — 30 I/min and up to 420heat loss and lower NPSHr exchangeable cold ends bar discharge pressure= V-belt drive by fixed or variable speed = Multi-cylinder models are supplied withelectric motor suction and return manifoldsLiquids Pumped= Pump and motor mounted on baseplatetogether with all required instrumentation = Nitrogen= Oxygen= Argon= Methane= Hydrogen
