Model 3-GUPDHigh Flow/High Pressure Pumps Specifications Available with SG cold end,1.625" boreFeatures & BenefitsRugged, heavy duty constructionallows for high reliability in oil wellservice operationsMain shaft is pressure lubricatedminimizing wear and tear on bearings/crosshead piston while keeping allcomponents coolInterchangeable with SG cold endsexpanding capabilities and all coldends have minimal material for quickcool-down and minimal wear and tearat start-upMultiple cold end sizes and drive endstrokes allow for wide range of flowsand pressures providing flexibility toend users and applicationsApplicationsOil well service* High pressure pumping systemsMobile pumping applicationsN, purgingLiquids PumpedNitrogen* MethaneEthylene125 x1.125 1.626x1.125 2.00x 1.125Bore x Stroke in 1.25x 1.3 {625 x 1.3 2.00x 1.31.28 515} 1.688x 1.5 2.00x 1.5gpm 15-18.3 2.6-32.0 3.9-488Flow Rate e e oIpm 6.7.-69.5 9.8-121.0 14.7-185.0Pump Design hp 205 205 205Rating kw 153 153 153Maximum psi 17,000 10,000 6,600Discharge Pressure bar 1472 690 455u N psi 60 60 60NPSPRbar 44 44 41Speed Range rpm 100 - 940 100 - 940 100 - 940 Consult Nikkiso ACD engineering to confirm available sizes and ratings.Typical Scope of SupplyFoot-mount pump shown(cold ends & drive end)Digital tach adapterLN, testedOptional AccessoriesSG, non-vacuum jacketed cold ends,p/n 60740-1Mechanical tach adapterBoost pump
