Variable Phase Turbine & Liquid Expander TurbineVariable Phase Turbine (VPT)Our latest Variable Phase Turbine (VPT) features a patented designthat efficiently handles liquid, vapor or any combination duringoperation. No other product currently available on the market iscapable of withstanding two phase fluids by design.The VPT’s flashing liquid expander technology offers significantefficiency improvements in liquid production while reducing the impactof vapor in the system. This technology can be applied to any LNGliquefaction process including the most common liquefactionprocesses—APCI and ConocoPhillips Cascade. It can be applied oneither the LNG mainstream or the MR refrigeration stream. In addition,it can replace the JT valve in any application.This product enhances targeted reduction in carbon emissions, anincrease in liquid production, overall process efficiency and areduction in vapor generation. It also provides further reduction in thedownstream pressure down tank pressure in APCI process.This turbine represents a significant step toward the reduction ofemissions while at the same time offering cost savings to ourcustomers. Proven tests have shown that return on customer’sinvestment can be achieved within 6-12 months, a significant valuelong term for customers.Benefits of the Nikkiso Pump Group VPT Product Line:Patented design which efficiently handles any combination liquid-vapor mixtures. Current available products are not able to withstandtwo phase fluids without breaking or damageParallel installation to Joule-Thompson valves to extract heat fromthe fluid and produce powerEnhances targeted reduction in carbon emissionsIsentropic (ideal) expansion, up to 85% efficiencyIncrease in liquid production, and reduction in vapor generationVPT accepts liquid and 2-phase fluid at inlet VPT delivers liquid and 2-phase fluid at outlet- Provides further reduction in the downstream pressure down tankpressure in APCI processProven tests have shown that return on customers investmentcan be achieved within 6-12 months 村 T 7 Nikkiso is committed to the continuous improvement of our productsand services to meet or exceed the requirements of our customers. It isthrough this commitment that Nikkiso ACD and Nikkiso Cryo hasdeveloped a reputation as a loyal and trustworthy supplier producingquality products known for their high reliability.
