ACD - Cryogenic Pumps EditionModel AC-14/14MTrailer Off-Loading PumpsSpecifications Pump Size units 1.5 x2.5x6.25Mgpm 20-200Flow Range —_——Ipm 75- 750feet 1.4-9.0NPSHR v O 一meter 042-27feet 440 -990Differential Head 1}meter 135-300hp 30-33Pump Design Ratingkw 22.5 - 25Speed Range rpm 4,200 - 8,200 Consult Nikkiso ACD engineering to confirm available sizes and ratings.1x2x4.5,1.5x25x6and1.5x 2.5 x 6.25MFeatures & Benefits= XP Inducer improves NPSH required= Gearbox design provides:- Improved efficiencies at higherspeeds- Higher operating range (flows andpressures)- Splash oil lube system for improvedbearing life and lower maintenancerequirements- Reduced vibration and noiseAll parts interchangeable withcomparable pumpStainless steel bearing house reduces“cold creep” into the gearboxApplications= Trailer off loading= Liquid storage transferLiquids Pumped= Nitrogen= Oxygen= Argon= MethaneTypical Scope of Supply= Pump, high performance gearbox driveand TEFC motor with purge ports= Splash lubricated gears= Long life (CFS) mechanical seal= |EC Motor frame
