Extremely High Strength:
e EDM wire-cut from high yield-strength stainless steel.
e Maximum allowable single-axis overload values are 4.2 to 15.2
times rated capacities.
e Through-hole available in some cases.
High Signal-to-Noise Ratio: Silicon strain gages provide a signal 75
times stronger than conventional foil gages. This signal is amplified,
resulting in near-zero noise distortion.
IP60, IP65 and IP68 (10m) Versions Available: An IP60 version is for use in
dusty environments. The IP65 version of the transducer provides
protection against water spray. The IP68 version is for underwater
environments to a maximum depth of 10 meters in fresh water Contact
All Industrial Automation for drawings and more information.
Typical Applications
e Rehabilitation research e Product testing e Orthopedic research Friction stir welding
The Omega160 F/T transducer
The transducer is made of hardened stainless steel,
and the tool and mounting adapters are made of high-
strength aircraft aluminum.
e Telerobotics
e Robotic assembly
SENSING RANGES
Axes
Fx, Fy (xlbf)
Fz (xIbf)
e Part placement and removal in precision fixtures
Calibrations
US-200-1000
500
US-300-1800
875
1500
US-600-3600
Tx, Ty (£Ibf-in)
1000
1800
3600
Tz (Ibf-in)
RESOLUTION
Axes
Fx, Fy (Ibf)
ENGLISH CALIBRATIONS
System Type*
(@8 Net/DAQ
Net/DAQ
Net/DAQ
Fz (Ibf)
1/8 1/16
5/17 5/34
1/4
Tx, Ty (Ibf-in)
/4 1/8
5/8 5/16
1/2
Tz (Ibf-in)
SENSING RANGES
Axes
Fx, Fy (£N)
Calibrations
SI-1000-120
SI-1500-240
SI-2500-400
Fz (£N)
2500
3750
6250
Tx, Ty (£Nm)
120
240
400
Tz (£Nm)
RESOLUTION
Axes
Fx, Fy (N)
METRIC CALIBRATIONS
120
System Type*
(GE Net/DAQ
240
Net/DAQ
400
Ne
t/DAQ
Fz (N)
Tx, Ty (Nm)
3/4
1/20
Tz (Nm)
1/20
*CTL: Controller F/T System; Net: Net F/T System; DAQ: 16-bit DAQ F/T System The resolution is typical for most applications and can be improved with filtering.
Resolutions quoted are the effective resolution after dropping four counts of noise (Net/DAQ) or eight counts of noise (CTL). All sensors calibrated by ATI.
Applied loads must be within range in each of the six axes for the F/T sensor to measure correctly (refer to the transducer manual for complex loading information).
