Single-Axis Overload English Metric Fxy +37000 Ibf +160000 N Fz +74000 Ibf +330000 N Txy +180000 Ibf-in +21000 Nm Tz +220000 Ibf-in +25000 Nm Stiffness (Calculated) English Metric X-axis & Y-axis force (Kx, Ky) 2.4x10° Ib/in 4.2x10° N/m Z-axis force (Kz) 3.2x10° Ib/in 5.6x10° N/m X-axis & Y-axis torque (Ktx, Kty) 2.7x10" Ibf-in/rad 3.0x10° Nm/rad Z-axis torque (Ktz) 5.5x10’ Ibf-in/rad 6.2x10° Nm/rad Physical Specifications English Metric Weight* 70 Ib 31.8 kg Diameter (OD,ID)* 10.0in, 2.12 in 260 mm, 54 mnm| Height* 3.74in 95 mm *Specifications include standard interface plates. Diameter excludes any connector block. ATI INDUSTRIAL AUTOMATION é—? INDUSTRIAL AUTOMATION Am 一 /sos001 hegistered ~ OMEGA250 (2)®10 Slip Fit 11 Customer Interface B.C. 160 136.569+0.025 56.569+0.025 MOUNTING SIDE Connector For Cable | Varies Depending on Sensor Selected Notes: 1. Material: Stainless Steel and Aluminum 2. Do not touch internal electronics or instrumentation. This could damage the transducer and will void the warranty. 3. For best accuracy, transducer must be mounted to surfaces rigid enough to support loads without deflection. (8) Tap M12X1.75 17 Equally Spaced Customer Interface Mounting Adapter plate: 57.8 Neoprene Rubber Dust Jacket Tool Adapter Plate Sensing Reference Frame Origin (2) 38.268+0.025 $295 (11) @ 127 Thru L 19193 ¥ 124 For M12 SHCS Customer Interface 30° Optional Mounting Pattern Mux & DAQ System 704 Net System ISOMETRIC VIEW Sensing Reference Frame Origin (2912 Slip Fit 710 69.2 一 | Customer Interface SIDE VIEW (8) Tap M12 x 1.75T 17 Equally Spaced Customer Interface 57.175 [957125 了 17 Customer interface B.C. $273.1 TOOL SIDE Customer Drawing # 9230-05-1266-05 VISIT WWW.ATI-IA.COM FOR CURRENT PRODUCT SPECIFICATIONS, 2-D DRAWINGS, AND 3-D CAD MODELS 39
