04 Top Loading I S LA Torsion Spring Loading Arms Product » Petroleum, Chemicals, etc: TSLA's feature the exclusive TB-NIIGATA Torsion Spring which provides balance through a wide range for smooth, shock-free operation, less wear on parts and complete operator control. Available with a variety of packing compounds and arm configurations. MLevel Sensor TB-NIIGATA can provided loading arm with level sensor system to acknowledge BUTTERFLYVALVE product level in the tank. LEVELSENSOR A M Drop pipe Coupler D c8 c1 c2 了 M Arm Length aunitotlength AmLengh Amopa| re | A B ¢ c2 Ca D 3200 | 1700 3B: 250 38,48 | 3400 | 1900 | 1500 | 1600 | 1500 | 600 |33:230 3700 | 2200 M Arm Style LOADINGARM 中 GODOWN AIR CONTROL VALVE ARLINE CABTYRE CABLE i AIRLINE CONNECTION: _/ MALE THREAD END. R3/8 MALE Butterfly Valve Simple design, light weight butterfly valves are available for petroleum and chemicals. Sensitive spring and high performance seal arrangement in the V.B. permit quick draining of loading arm. Vacuum Breaker Valve Torsion Spring A variety of strength of single spring models assures that established moment load maximums are not exceeded. EXPLOSIONPANEL by Oers) ONORACKT + SUPPLIED BY TEN + SUPPLIED OTHERS LOADING ARMS V R A Vapor Recovery Arms Product » Gasoline, Condensate, etc. VRA is a compact, one-piece arm assembly to recover air-gas mixture while loading products, Equipped with an air cylinder, arm operation and sealing the dome are completely accomplished. = c A M Arm Length auitofength Am Length AmDa. | AT 2o A B ¢ D 3200 1700 38,48 | 3400 1900 1500 | 尖山 | sso 3700 2200 - M Vapor Seal Plug V RA with Steam Jacket ‘ Product » Sulfur, Asphalt, etc. ] Steam jacketed arms are designed to handle high temperature products such as asphalts, liquid sulphur, and are incorporating the Internal Jacketed Joints (ISJ) or External Jacketed Joints (ESJ). M 1SJ (Internal Steam Jacketed) Swivel Joint Packing Steam Line Swivel Joint Air Cylinder Air actuator to force loading arm downward Dynamic-seal packing and two rows of bearings in to seal the dome flame-hardened races during loading in each swivel. products. Provided with long life lubrication. 05
