05S Huzhou SanjingM Cryogenic Equipment Co., Ltd.L-CNG BERL-CNG High Pressure Pumps主要用于 L-CNG 天然气加气站高压气瓶的充装。机组主要为单列 / 双列 /三列活塞式泵。Such pumps are mainly used for filling high pressure gas cylinders at L-CNG natural gas stations. Theunits are mainly piston puups with single,double three cold ends.适用范围 Applicability 主要技术参数 Main technical parameters@ L-CNG 天然气加气站高压气瓶充装 @ 流量 : 500-10000 Lh@ 城市天然气调峰站管网补气、增压 @ 出口压力 : 1.0-35.0 MPa@ 杜瓦瓶充装 @ Flow: 500-10000 L/h© Filling of high pressure gas cylinders at © Maximum exit pressure: 1.0-35.0 MPaL-CNG natural gas stations@ Urban natural gas peak shaving station pipe networkgas supplementand pressure boost© Filling of LNG Dewar bottles 标准配置 Standard configuration@ 进液过滤器 @ Liquid inlet filter@ 出液压力表及根阀 @ Liquid outlet pressure gauge and root valve@ 传动箱油温传感器 @ drive box oil temperature sensor@ 进液、回气金属软管 @ Liquid inlet, return air metal hose@ 阻尼器 © Damper 性能特点 Performance features@ 所有电气部件按照防爆要求配置@ 采用高真空夹套泵头 ,真空度达到 10-5 扎 ,最大限度减小冷损@ 特殊材料活塞密封，活塞密封寿命长达 4000h 以上@ 出口压力脉冲小，电机载荷平稳@ 传动箱采用自润滑系统，运行平稳，且配置有油温联锁装置，对传动箱温度进行监控，并与控制联锁，保障机组安全@ All electric components are configured as per anti-explosion requirements.@ A high vacuum jacket pump head is used, and the vacuum degree reaches 10 torr to reduce cold lossto the greatest extent.The piston seal is made of special material and the service life of the piston seal is over 4,000 hours.The exit pressure pulse is small and the motor load is steady.© The transmission case has a self-lubricating system and it operates in a steady manner. In addition,it is equipped with an oil temperature interlocking device to monitor the transmission case temperature,and the device interlocks with the control system so as to guarantee the safety of the unit. © 0 L-CNG 和泵性能参数表Table of L-CNG Performance Parameters流量进口压力出口压力功率接口尺寸 Size型号 i # A prlensl:flre < Power mm(DN): - =" RO Sh VPRl |EEPa(dl Kw Liqfifinlet LU Retum airSBP-800/250 1 800 | 00216 @ 25 15 32 15 25SBP-1000/250 | 1 1000 | 00216 | 25 15 32 15 25双列SBP-1500/250 | 2 1500 | 0.02-16 | 25 2 50 15 32SBP-20001250 | 2 2000 | 00216 | 25 30 50 15 32=73SBP-2500/250 | 3 2500 | 00216 | 25 37 50 20 40SBP-3000/250 | 3 3000 | 002416 | 25 45 50 20 40SBP-3500/250 | 3 3500 | 00216 | 25 45 50 20 40SBP-4000/250 | 3 4000 | 002416 | 25 55 50 20 40SBP-4500/250 | 3 4500 | 00216 | 25 75 50 20 40SBP-5000/250 5000 | 00216 | 25 75 50 20 40SBP-10000/350 | 3 10000 | 00216 | 35 160 65 25 50 注 : 表内参数为我公司标准产品，如需定制，请咨询技术部 : 0572-2287769Note: the above parameters are for our standard products. Please consult the Technology Department: 0572-2287769if you need custom-made products.08
