S Huzhou Sanjing HE Cryogenic Equipment Co., Ltd. SRR Carbon Dioxide Pumps 适用范围 Applicability @ 主要用于液体二氧化碳二氧化碳液体钢瓶充装供气配气系统 Filling of carbon dioxide liquid cylinders; Air supply, air distribution systems @ @ @ Such pumps are mainly used for liquid carbon dioxide; o o 主要技术参数 Main technical parameters @ 流量 : 100-4000 Lh @ 最大出口压力 : 10.0 MPa @ Flow: 100-4000 Lh @ Maximum exit pressure: 10.0 MPa 性能特点 Performance features ooooeo9o 预冷快，泵内不易形成干冰简洁的泵头组件设计，便于维护保养新型密封填料设计，超长寿命维修方便 ,常规维修只需两小时可 24 小时连续运行 The precooling is fast, which makes it not easy to form dry ice inside the pump. The simple pump head module design facilitates maintenance. The pump has the design of new type gland packing and ultra-long service life. Maintenance is convenient: it merely takes two hours to perform a routine maintenance- The pump can be continuously operated for 24 hours 二氧化碳泵参数表 Table of Carbon Dioxide Pump Parameters 流量进口压力 | 出口压力 | 功率接口尺寸 Size 型号 g | Fow pr{enslgfire Prl\e/lsasxure Pover mm(DN) S 5 e Hodel Ne I MPa MPa KW Licfifinlet Liqfid;futlet Retu?l: air SBP 100-400/100 1 100-400 1.38-2.4 10 5.5 25 20 25 SBP 300-600/100 1 300-600 1.38-2.4 10 55 25 20 25 SBP 500-900/100 1 500-900 1.38-2.4 10 55 25 20 25 SBP 600-1200/100 1 600-1200 1.38-2.4 10 7.5 25 20 25 SBP 1000-2000/100 1 1000-2000 | 1.38-2.4 10 15 32 20 25 注 : 表内参数为我公司标准产品，如需定制，请咨询技术部 : 0572-2287769 Note: the above parameters are for our standard products. Please consult the Technology Department: 0572-2287769 if you need custom-made products. KREPEFER Large Flow and Medium Pressure Piston Pumps 适用范围 Applicability @ 主要用于液氧液氨液握液化天然气 @ 大中型钢厂供气系统性能特点 Performance features @ 杜瓦瓶充装 @ 模块化设计，流量覆盖范围广 . @ 储槽充装 @ 采用高真空夹套泵头 ,真空度达到 10 毛 , 冷 @ Such pumps are mainly used for liquid oxygenliquid 损小 nitrogen, liquid argon and liquefied natural gas. @ 可靠地密封结构 @ Airsupply systems atlarge and medium steel mills @ 多种配置提高泵的安全性和自动化程度 Filling of Dewar bottlers @ The pump has modular design and a wide @ Filling of storage tanks coverage of flow. A high vacuum jacket pump head is used, = 5 主要技术参数 Performance parameters and the vacuum degree reaches 105torr so @ 流量 : 4000-72500 L/h as to reduce cold loss. @ 最大出口压力 : 8.0 MPa @ lt has a reliable sealing structure. @ Flow: 4000-72500 L/h @ Multiple configurations enhance the safety and @ Maximum exit pressure: 8.0 MPa automation degree of the pump. 大流量中压活塞泵参数表 Table of Large Flow and Medium Pressure Piston Pump Parameters 流量进口压力 | 出口压力 | 功率接口尺寸 Size Inlet Max 型号 5T Flow pressure | Pressure | Power mm(DN) Madel NO. Lh MPa MPa KW | 进液 | 出液 | 回气 Liquid inlet | Liquid outlet | Return air SBP 4000-8000/80 3 4000-8000 0.02-1.6 8.0 37 65 40 40 SBP 5000-10000/80 3 5000-10000 0.02-1.6 8.0 45 65 40 40 SBP 8000-15000/80 3 8000-15000 0.02-1.6 8.0 75 65 40 40 SBP 10000-20000/80 3 10000-20000 | 0.02-1.6 8.0 90 65 40 40 SBP 10000-25000/60 3 10000-25000 | 0.02-1.6 6.0 90 100 65 50 SBP 10000-30000/60 3 10000-30000 | 0.02-1.6 6.0 90 100 65 50 SBP 72500/60 5 72500 0.02-1.6 6.0 185 150 80 80 注 : 表内参数为我公司标准产品，如需定制，请咨询技术部 : 0572-2287769 Note: the above parameters are for our standard products. Please consult the Technology Department: 0572-2287769 if you need custom-made products. 12
