S Huzhou Sanjing 国画 Cryogenic Equipment Co., Ltd. 适用范围 Applicability @ 主要用于液氧 BRE. RE. 液化天然气 @ 各种轻中高负荷钢瓶充装 @ 各类储负充装 @ 供气配气系统 @ Such pumps are mainly used for liquid oxygen, liquid nitrogen, liquid argon and liquefied natural gas. Filling of all kinds of cylinders with light, medium and high loads Filling of all kinds of storage tanks Air supply, air distribution systems 主要技术参数 Main technical parameters @ 流量: 50-5000 L/h @ 最大出口压力 : 16.5 Mpa-120 MPa @ Flow: 50-5000 L/h Maximum exit pressure: 16.5 Mpa120 MPa 性能特点 Performance features @ 经典设计 ,性能稳定 ,寿命达 20 年 ; @ 采用高真空夹套泵头 ,真空度达到 10 巨 , 冷损小 ; @ 密封可靠 ,填料寿命达 15 万瓶次 ,活塞环寿命长达 30 万瓶次 ; @ 可选配气体辅助密封装置，进一步提高密封寿命 ; @ 维修方便 ,常规维修只需两小时 ; @ 可 24 小时连续运行 @ Asuch pump has classic design and stableperformancesi its service life can reach 20 years; @ Ahigh vacuum jacket pump head is used, and the vacuum degree reaches 1075 torr so as to reduce cold loss; o lts seal is reliable: the service life of packing can each 150,000 times/cylinder and the service life of the piston ring is as long as 300,000 times/cylinder; @ An auxiliary gas sealing device can be equipped to further enhance the service life of the sealing element'; @ Maintenance is convenient: it merely takes two hours to perform a routine maintenance; The pump can be continuously operated for 24hours. 工业气体充瓶泵参数表 Table of Industrial Gas Filling Cylinder Performance Parameters 流量计电夺鸭名时且才功率接口尺寸 Size 型号 5T 8 Flow pressure | Pressure | Power mm(DN) e Model N Lt MPa MPa KW Liqlfdfi[et Liq{fidpofflel Rem SBP50-150/165 1 50-150 0.02-0.8 16.5 4 25 10 25 SBP100-250/165 1 100-250 0.02-0.8 16.5 4 25 10 25 SBP200-350/165 1 200-350 0.02-0.8 16.5 4 25 10 25 SBP200-450/165 1 200-450 0.02-0.8 16.5 5.5 25 10 25 SBP300-600/165 1 300-600 0.02-0.8 16.5 75 25 10 25 SBP300-700/165 1 300-700 0.02-0.8 16.5 11 25 10 25 SBP400-800/165 1 400-800 0.02-0.8 16.5 11 32 15 25 SBP500-1000/165 1 500-1000 | 0.02-0.8 16.5 11 32 15 25 SBP600-1200/165 1 600-1200 | 0.02-0.8 16.5 15 32 15, 25 SBP200-450/250 1 200-450 0.02-0.8 25 7.5 32 15 25 SBP300-600/250 1 300-600 0.02-0.8 25 11 32 15 25 SBP400-800/250 i 400-800 0.02-0.8 25 15 32 15 25 SBP200-450/350 1 200-450 0.02-0.8 35 11 32 15 25 SBP300-600/350 1 300-600 0.02-0.8 35 15 32 15 25 XX 3 SBP800-1500/165 2 800-1500 | 0.02-0.8 16.5 15 40 15 32 SBP1000-2000/165 2 1000-2000| 0.02-0.8 16.5 22 40 15 32 SBP1000-2500/165 2 1000-2500 | 0.02-0.8 16.5 30 40 15 32 SBP800-1500/250 2 800-1500 | 0.02-0.8 25 22 40 156 32 SBP800-2000/250 2 800-2000 | 0.02-0.8 25 30 40 15 32 SBP800-1500/350 2 800-1500 | 0.02-0.8 35 37 40 15 32 三列 SBP1500-3000/165 3 1500-3000 | 0.02-0.8 16.5 30 50 20 40 SBP2000-4000/165 3 2000-4000| 0.02-0.8 16.5 37 50 20 40 SBP2000-4500/165 3 2000-4500| 0.02-0.8 16.5 37 50 20 40 SBP2500-5000/165 3 2000-5000| 0.02-0.8 16.5 37 50 20 40 SBP1500-3000/250 3 1500-3000| 0.02-0.8 25 45 50 20 40 SBP2000-4500/250 3 2000-4500| 0.02-0.8 25 75 50 20 40 SBP1500-3000/350 3 1500-3000 | 0.02-0.8 35 55 50 20 40 注 : 表内参数为我公司标准产品，如需定制，请咨询技术部 : 0572-2287769 Note: the above parameters are for our standard products. Please consult the Technology Department: 0572-2287769 if you need custom-made products. 10
