ACD - Cryogenic Pumps EditionModel P1100Cylinder Filling Pumps Features & Benefits= Vertically positioned floating pistonmeans longer life= Simple cold end design assembly,easy maintenance= Large piston diameter and longerpump stroke mean slower speeds andsmooth operation= Pump packing is easily adjustedthrough a large access port, whichallows for extended packing life= Splash oil lubricated drive providesextended pump life and minimizesmaintenance requirementsSpecifications\19 in 1.75 x 1.50Bore x Strokemm 44.5x38m 19-61Flow Rate i =Ipm 7.2 =231Min. 200psi 2 = 2 &Max. 450Suction PressureMin. 18.7bar - vMax. 31Pump Design Rating hp 5-10@1000 psi (69 bar) kw S7-76Maximum psi 1,000Working Pressure bar 69Speed Rating rpm 140 - 450Skid Settings High pressure relief valve setting 1,200 psi (82.7 bar)High pressure bypass relief valve setting1,000 psi (69 bar)Burst disc pressure point 2000 psi (138 bar) Consult Nikkiso ACD engineering to confirm available sizes and ratings.Applications= Carbon dioxide cylinder filling= Nitrous oxide cylinder fillingLiquids Pumped= Carbon Dioxide= Nitrous OxideFOR PUMPS INTENDED TO BE USED IN NITROUS OXIDE SERVICE:Liquid Nitrous Oxide is a potentially dangerous fluid and must be handled with extreme care. See Compressed Gas Association standard CGA G-8.3-2016 forfurther information. Under certain combinations of temperature and pressure Nitrous Oxide can explosively decompose with serious consequences. NitrousTypical Scope of Supply (SKID)Cold end and drive assembly,TEFC electric motorGalvanized steel base plate with driveNEMA 1 pushbutton starterSurge chamberRelief valve and burst discPressure gauge and snubberSafety bypass relief valve arrangementautomatically returns liquid to tank at1000 psi (69 bar)Oil lubricated drive end(oil shipped loose)Oxide is an oxidizer that actively supports combustion. Nitrous Oxide handling equipment must be cleaned for Oxygen service. Design and construction ofstorage and piping systems for pumping liquid Nitrous Oxide must assure material compatibility and be such as to prevent loss of prime or “dry running” ofpumps. Nitrous Oxide is an active solvent for many materials and material compatibility with Nitrous Oxide must be confirmed before their use. For additionalhistorical information relating to hazards associated with Nitrous Oxide decomposition refer to Chemical Safety Board report number 2016-04-|-FL DatedFebruary 2017.
