装卸臂附件 软管盖
OPW-=> 命 LOADING
ENGINEERED SYSTEMS
a S, company
Loading Rack Hose Covers
Hose covers are a natural option for all OPW bottom
loading arms. These easy-to-install, zippered covers help
drivers quickly identify the product being handled. This
not only helps protect the equipment, but also helps avoid
costly cross contamination of product.
。 Prevent unsightly scuffs to costly tank logos
¢ Visually identify petroleum products
¢ Protect drivers from protruding wires
。 Available in all API color codes
。 Custom lengths and sizes available
Construction Details
。Inner Jacketing: Sun-Resistant Heavy-Duty Nylon
。Outer jacketing: Sun-Resistant, Heavy-Duty Nylon
。Inner Core: Foam
。 Thread: PTFE-Coated Fiberglass Thread
。 Attachments: Heavy-Duty Zipper
Deflectors
To prevent static build-up, foaming, impinge-
ment on the bottom of the tank and to keep
the drop pipe from rising, OPW Engineered
Systems manufactures both T-style and cone-
type deflectors. Available in 2" through 6"
sizes, the standard product is made of
aluminum. Other materials of construction OPW-ES 363 OPW-ES 463 OPW-ES 464
are available to meet the needs of more Cast aluminum with female 。 Cast aluminum with female Cast aluminum tee with
corrosive chemicals. threads for 2" or 6" liquid threads for 3" or 4" liquid female threads. Especially
loaders used on gravity loaders. Vertical wing ribs designed for handling jet fuel.
discharge lines. prevent drop tube from Prevents high-velocity
rising when filling. Accelerates impingement on bottom of
discharge and prevents tank to reduce possibility of
roiling of product when used ignition of jet fuel. Available
on pressure discharge line. in3"and 4".
Strainers
OPW strainers are used on suction lines during the unloading of tank cars to
prevent scale and other foreign objects from being sucked into the line. This
aluminum-cast product is designed with legs on the outlet to keep the inlet
off the bottom of the tank. It has a 4-mesh galvanized-steel screen. The inlet
is standard internal pipe threads. Available in 3" and 4" sizes.
OPW-ES 341
opw-es.com
28 P
