Rack Monitors
OPW Engineered Systems supplies a complete line of CIVACON™ brand
rack monitors used in loading and unloading operations. The monitors
can detect the type of sensor, the state of liquid in the tank, an overfill
situation, and/or verify the grounding condition.
8030 Series Ground Verification
Monitor - Ground Only Monitor
The CIVACON™ model 8030 Ground Verification Monitor is compatible with
today's transport ground systems. The monitor is 5 amperage, 240-volt relay
output for control of terminal automation systems (TAS), or pump control
devices when used as a stand-alone system. The monitor is equipped to
provide a permissive signal to allow load rack operation and, if ground is
lost, to indicate a non-permissive signal and shut down the loading operation.
ORDERING SPECIFICATIONS
8030-120 Ground verification monitor with indicator lamps — 120V
8030-240 Ground verification monitor with indicator lamps — 240V
OPTIONAL ACCESSORIES
7620-7620 Ground verification plug, dual ball with 30 ft. straight cord
7690-7690 Ground verification plug, dual ball with 30 ft. straight cord
& junction box
7720-7720 Ground verification clamp with 30 ft. straight cord
7790-7790 Ground verification clamp with 30 ft. straight cord & junction box
SPECIFICATIONS - 8030 SERIES GROUND VERIFICATION MONITORS
LOADING ARM ACCESSORIES
Ground Only Monitor
Operating Temperature: -40°F to 158°F Output Relay Contacts: 240 VAC - 5A
)0, 0,
(40°C Q0 Electrical Connections: Internal Terminal
Input Requirements: 120 VAC 60 Hz, Strips
10 VA (Standard); 240 VAC version
Enclosure: NEMA 4 explosion-proof
available = :
aluminum housing
Approximate Weight: Model 8030 - 13 lbs.
(6 KG)
Approvals: UL/CUL Class I, Division |,
Groups C&D
