O PVW-> 盒 / CUSTOM APPLICATIONS
a company i
D-32-FF
D-32-FF Scissor Arm
with Valve Outboard
for Viscous Products
Boom-Type Loader
with Self-Draining Configuration
(Note: The primary arm section is angled down
for drainage)
1000-RC
U o '\ \
C-32-RF
C-33-RF Scissor Arm
with Downfeed Loading
¢ Deadman loading valve with remote control
operating lever and outlet deflector
Remote Control Unit (1000-RC)
The OPW 1000-RC remote control unit provides
convenient control of the loading valve from the
outboard end of the loading arm. The 1000-RC consists
of an arm clamp, lever handle and connection rod.
Available for all OPW Type A, B, C and E liquid loaders.
opw-es.com
26
Drum/Tote-Filling Arms
¢ Makes it easy to load both open drums and those with
small bung openings
¢ Designed to provide the range of flexibility
needed for loading drums/totes at any
orientation on pallet
¢ Easy operation ensures faster loading
By-Pass Loading Arms
OPW By-Pass Loading Arms are designed as a low-cost
alternative to arms constructed of Hastelloy®, Alloy 20° and
other specialty metals used to transfer hydrochloric acid
and other corrosive chemicals.
This unique design offers:
¢ All the ease of operation and handling advantages of
conventional spring-balance loaders
e Liquid bypass of steel swivel — no liquid passes through
the base swivel
* Base swivel, in conjunction with torsion spring, serves as
a support and carrying mechanism only
¢ Flow passage — consists of lined pipe, plastic pipe, and
a hose suspended from the support arm
¢ Available in 2", 3" and 4" sizes in a variety
of configurations
